Cryogenic Labels for Laboratory Cold Storage
- Rated for -80 °C ULT freezer storage and -196 °C liquid nitrogen systems
- Adhesive maintains bond on polypropylene and glass across full cold storage range
- Frost-resistant polyester face — print legible through condensation on retrieval
- Suitable for cryovials, microcentrifuge tubes, blood collection tubes, and cryoboxes
- Resistant to freeze-thaw cycling between cold storage and ambient temperatures
Cold Storage Sample Identification from -80 °C Freezers to Liquid Nitrogen
Cryogenic Labels for Laboratory Cold Storage are engineered for biological and chemical sample repositories that store materials across the complete range of cold storage temperatures — from -20 °C conventional freezers and -80 °C ultra-low-temperature (ULT) mechanical freezers through to -150 °C to -196 °C liquid nitrogen vapour-phase and liquid-phase cryostorage systems.
The label must perform reliably at whichever temperature the sample resides, and in many biobank and clinical research settings, the same sample tube will experience multiple temperature transitions over its storage lifetime as it is retrieved, thawed for analysis, and returned to storage.
VIZLENT engineers Cryogenic Labels for Laboratory Cold Storage with an adhesive and face material combination that maintains bond integrity and print legibility through this full temperature range and through the mechanical stresses of repeated cold storage retrieval cycles.
- A key differentiation of VIZLENT’s Cryogenic Labels for Laboratory Cold Storage is the validation of label performance specifically on the polypropylene substrates of the most commonly used laboratory tube brands, rather than on generic flat substrates.
- Polypropylene cryovials and microcentrifuge tubes have a curved surface geometry and a very low surface energy that together challenge standard adhesives more severely than flat or higher-surface-energy substrates.
- By testing and specifying adhesive performance on representative cryovial surfaces at the target storage temperature, VIZLENT provides procurement managers and laboratory quality assurance teams with meaningful performance data for their specific tube and storage system combination.
Applications
ULT (-80 °C) freezer biobank tube and rack identification in pharmaceutical and academic research settings; liquid nitrogen vapour-phase storage of biological cell banks, tissue samples, and clinical trial specimens; clinical laboratory refrigerated and frozen serum and plasma archive tube labelling; environmental sample archive cold storage identification in analytical chemistry laboratories; food safety and agricultural research sample cold storage tracking; repository migration — relabelling tubes when transferring between storage systems at different temperatures.
Specifications
Cryogenic Labels for Laboratory Cold Storage should be specified by the lowest storage temperature in the repository (to select the correct adhesive grade), the tube substrate material and brand (to confirm adhesive compatibility), and the number of expected freeze-thaw cycles over the sample’s planned storage period.
| Item | Cryogenic Labels for Laboratory Cold Storage |
|---|---|
| Brand | Vizlent |
| Storage Temperature Range | -196 °C (LN₂) to +80 °C; covers -20 °C, -80 °C, and LN₂ storage |
| Adhesive Type | Cryogenic-grade acrylic — low glass transition temperature formulation |
| Substrate Compatibility | Polypropylene, glass, HDPE; validated on standard cryovial tube formats |
| Face Material | White polyester (PET) — frost-resistant, no embrittlement at -196 °C |
| Printing Method | Thermal transfer (resin ribbon); laser; direct thermal (ambient grade only) |
| Barcode Formats | Code 128, Data Matrix ECC200, QR Code; barcode grade maintained post-cryo |
| Chemical Resistance | DMSO, ethanol, glycerol, IPA, aqueous buffers and cryoprotectant solutions |
| Freeze-Thaw Performance | Adhesion and print integrity maintained through multiple freeze-thaw cycles |
| Available Formats | Side wrap-around, cap-top dot, cryobox lid label; custom format available |
| MOQ | 1,000 labels per format and specification |
| Sample | Available for validation testing on customer tube types |
| Payment Term | T/T 30% deposit, balance before shipment |
| Production Time | 10–18 working days after artwork approval and deposit |
Performance Standards
Cryogenic Labels for Laboratory Cold Storage are relevant to ISBER Best Practices for Repositories (specimen label adhesion and legibility requirements across cold storage temperatures), ISO 20387 (biobanking — general requirements for biobanking), and CLSI AUTO12-A (laboratory specimen labelling and barcode standards), which together establish the durability, scan reliability, and traceability requirements for sample labels used across the range of laboratory cold storage systems.
Certifications
VIZLENT manufactures Cryogenic Labels for Laboratory Cold Storage under ISO-certified quality management processes and validates adhesive bond strength and barcode readability at -80 °C and -196 °C storage conditions, making them appropriate for biobank, pharmaceutical, clinical research, and academic laboratory cold storage programmes in the EU, US, and Asia-Pacific markets.
You May Also Need
-
Laboratory Cryogenic Resistant Labels for 2ml Tubes Sized and calibrated for precise fit on standard 2 ml cryovial tube formats Cryogenic-grade adhesive rated to -196 °C on polypropylene cryovial bodies Wrap-around format engineered to avoid cap junction — prevents bridging and lifting Frost-resistant polyester face — print and barcode legible through condensation Dimensionally stable at […]
-
Cryo Laboratory Labels for Liquid Nitrogen Storage Survives direct immersion in liquid nitrogen at -196 °C without bond failure Cryogenic adhesive formulated for polypropylene cryovial bond strength at LN₂ temperature Frost-resistant face — barcodes and text remain scannable through surface ice Available for liquid-phase immersion and vapour-phase LN₂ storage systems Resistant to DMSO, ethanol, and […]
-
Cryogenic Labels for Laboratory Cold Storage Rated for -80 °C ULT freezer storage and -196 °C liquid nitrogen systems Adhesive maintains bond on polypropylene and glass across full cold storage range Frost-resistant polyester face — print legible through condensation on retrieval Suitable for cryovials, microcentrifuge tubes, blood collection tubes, and cryoboxes Resistant to freeze-thaw cycling […]
-
Laboratory Cryogenic Labels Rated to -196 °C for liquid nitrogen and vapour-phase cryostorage Cryogenic adhesive bonds to polypropylene, glass, and HDPE sample containers Frost-resistant polyester face maintains print legibility through condensation and ice Dimensionally stable — no shrinkage, cracking, or embrittlement at cryogenic temperatures Chemical resistant to DMSO, ethanol, glycerol, and aqueous cryoprotectant solutions Send […]
-
Laboratory Sample Identification Labels Suitable for tubes, microcentrifuge vials, plates, and sample containers Available for ambient, refrigerated, frozen, and cryogenic storage temperatures Chemical-resistant face material withstands ethanol, IPA, DMSO, and common lab reagents Compatible with thermal-transfer, laser, and direct-thermal laboratory printers Supports 1D barcodes, 2D Data Matrix, and QR codes for LIMS integration Send Your […]
-
Liquid Nitrogen Label for 2ml Laboratory Tube Rated for continuous immersion in liquid nitrogen at -196 °C Cryogenic acrylic or rubber-based adhesive maintains bond at ultra-low temperatures Sized precisely for standard 2 ml microcentrifuge and cryovial tube formats Frost-resistant face material — print remains legible through ice and condensation Compatible with thermal-transfer, laser, and direct-thermal […]
Frequently Asked Questions
Yes. VIZLENT manufactures Cryogenic Labels for Laboratory Cold Storage in custom dimensions for the full range of laboratory tube formats used in cold storage programmes, from 0.5 ml microcentrifuge tubes through 2 ml cryovials to 15 ml and 50 ml conical tubes, blood collection tubes, and cryobox lids. Each tube format requires a specific label width and length to achieve the correct circumferential wrap, and larger tubes may benefit from a wider label face to accommodate more print content. Please provide tube brand and dimensions when requesting a quotation.
During retrieval from -80 °C storage, condensation forms on the tube surface as it warms through the dew point — this is the most common condition under which standard labels fail, as moisture infiltrates the label edge and disrupts the adhesive bond. VIZLENT’s Cryogenic Labels for Laboratory Cold Storage use a polyester face material with a moisture-resistant adhesive that is specifically formulated to resist edge-wicking of condensation water. The label edge seal remains intact through the condensation phase, and the polyester face does not absorb moisture, ensuring that the label remains bonded and the print content remains readable and scannable as the tube warms to ambient temperature.
The minimum order quantity for Cryogenic Labels for Laboratory Cold Storage is 1,000 labels per specification. Production lead time is 10–18 working days from artwork approval and deposit receipt. VIZLENT strongly recommends that new customers request validation samples before placing a production order, allowing the laboratory quality team to verify adhesive performance on their specific tube brand and cold storage system before committing to volume. Validation sample sets are dispatched within 3–5 working days of request.
For best adhesion on polypropylene cryovials, VIZLENT recommends applying labels at ambient room temperature (not directly from a refrigerator or freezer) to a clean, dry tube surface. Tubes that have been rinsed with ethanol or IPA should be allowed to fully dry before label application, as residual solvent on the surface can reduce initial tack. Applying the label with firm finger pressure across the full label area — particularly at the leading and trailing edges — ensures complete contact between the adhesive and the tube surface. Labels should be applied at least 30–60 minutes before initial freeze-down to allow the adhesive to establish full bond strength before cold shock.
Yes. VIZLENT supplies Cryogenic Labels for Laboratory Cold Storage with consistent die-cut dimensions and controlled label thickness, which are important for reliable tube handling in automated sorters and robotic cryostorage systems where label height and diameter consistency affect gripper and rack slot clearance. We can specify label construction to maintain total tube diameter (tube OD + 2× label thickness) within the tolerance range required by specific automated storage systems. Please provide the system manufacturer’s label specification requirements when ordering to allow us to confirm or adjust the label construction accordingly.
