Wrap Around Label Cable Labels for Industrial Identification
- Self-laminating wrap-around format
- Sealed print under transparent overlay
- UL 94 V-0 flame-retardant film
- Strong permanent acrylic adhesive
- Stable from -40 °C to 105 °C
- Resists oils, fuels, and cleaners
Wrap Around Label Cable Labels for Industrial Identification Features
Wrap Around Label Cable Labels for Industrial Identification from Vizlent deliver durable, long-term identification for wiring in machinery, control panels, and process equipment.
Each label combines a printable white zone with a clear self-laminating tail that wraps over the printed area, forming a sealed, abrasion-resistant identification ring that withstands oil mist, washdown, and routine handling on the plant floor.
The flexible vinyl or polyester face stock is UL 94 V-0 rated and conforms to a wide range of cable diameters without lifting at the seam. With a high-tack permanent acrylic adhesive and standard barcode-friendly print zone, the wrap around label cable labels integrate cleanly into existing thermal transfer and laser printing workflows.
Specifications
| Item | Wrap Around Label Cable Labels for Industrial Identification |
|---|---|
| Brand | Vizlent |
| Material | Flame-retardant vinyl or polyester film |
| Construction | White print zone + clear self-laminating tail |
| Flame Rating | UL 94 V-0 |
| Temperature Resistance | -40 °C to 105 °C continuous |
| Adhesive Type | Permanent high-tack acrylic |
| Adhesive Performance | Resists oils, fuels, and washdown chemicals |
| Cable Diameter Range | 2–25 mm typical; custom available |
| Thickness | 50–75 μm face stock |
| Printing Compatibility | Resin thermal transfer or laser printer |
| Format | Rolls or A4/letter sheets |
| MOQ | 1,000 pcs |
| Sample | Free stock samples; custom samples chargeable |
| Payment Term | T/T, PayPal, L/C |
| Production Time | 7–12 working days after artwork approval |
Applications:
Machine tool builders, packaging line OEMs, oil and gas instrumentation, mining electrical systems, water treatment control panels, and renewable energy power converters.
You May Also Need
-
Circuit Board Label & PCB Labels Comprehensive range covering pre-reflow, post-reflow, and standard-service PCB labelling Face material options: polyimide (PI), white-coated PI, high-temp PET, standard PET Adhesive options matched to process temperature: silicone, high-temp acrylic, or standard acrylic Compatible with FR-4, ceramic, aluminium PCB, flex circuit, and component body surfaces Supports thermal-transfer, laser, and pre-printed […]
-
Automatic PCB Labelling Heat Resistant Labels Precision die-cut labels on accurately wound rolls for automated label applicators Consistent label gap and registration enables reliable tamp-blow and wipe-on application Polyimide face rated for lead-free SMT reflow up to 260 °C High-temperature silicone adhesive — stable, non-flowing, no outgassing at reflow White-coated polyimide face option for high-contrast […]
-
300 Degree Polyimide Labels for Semiconductor and Printed Circuit Board Manufacturing Processes Polyimide film rated for short-duration exposure up to 300 °C Survives semiconductor backend packaging processes and high-temperature cure ovens High-temperature silicone adhesive stable at continuous 260 °C and short-peak 300 °C No thermal decomposition, discolouration, or dimensional change at rated temperatures Send Your […]
-
Data Matrix Polyimide Labels for PCB identification Data Matrix ECC200 code encodes high data density in a compact square symbol Polyimide base film rated for continuous and peak service to 260 °C Survives lead-free SMT reflow without code degradation or delamination White-coated polyimide face provides high print contrast for reliable 2D scan rates Supports very […]
-
PCB Labels for Printed Circuit Board and Electronics Broad substrate compatibility: FR-4, ceramic, aluminium, and flex PCBs Heat-resistant polyimide or high-temperature polyester face material Stable adhesion through reflow, wave soldering, and cleaning processes Supports thermal-transfer, laser, and pre-printed barcode and QR code formats Available with sequential serial numbers, Data Matrix, Code 128, or QR codes […]
-
PCBs Labels Heat Resistant Labels Withstands SMT reflow soldering peak temperatures up to 260 °C Polyimide or high-temperature polyester face material options High-temperature silicone or acrylic adhesive — no bleed, no char Dimensionally stable through thermal cycling — no curl or shrinkage Compatible with thermal-transfer (resin ribbon) printing for permanent legends Send Your Inquiry Now […]
-
Adhesive Cable Labels Self Laminating Vinyl Labels from Vizlent offer strong bonding, print protection and durable wire identification.
-
Wrap-around Clear Laminated Cable Wire Marker Labels by Vizlent protect printed IDs with clear laminate, ensuring durable wire tracking.
-
Vinyl Wrap Around Cable Labels from Vizlent deliver flexible cable marking, strong adhesion, weather resistance and lasting identification.
Frequently Asked Questions
Yes. We design each layout around the customer’s cable outer diameter range, adjusting the printable white zone and the length of the clear self-laminating tail to give a clean wrap with at least one full revolution of overlap. Custom layouts can be combined into mixed-SKU rolls for efficient production.
The clear film tail seals the printed image under a continuous protective layer that resists oils, cutting fluids, coolants, IPA, and mild alkaline washdown chemistry. This makes VIZLENT wrap around cable labels well suited to machine tools, packaging lines, and food and beverage production cells.
Plan for a minimum of 1,000 pieces per layout and 7–12 working days of production time after artwork approval. For programs with predictable demand we can offer blanket orders with scheduled call-offs to flatten lead time for downstream OEM assembly.
Long-term legibility is the single most important attribute for cable identification in industrial settings. The self-laminating construction protects the print from UV, abrasion, and chemicals, so the markers remain scannable and human-readable across decades-long machine service intervals.
Yes. Our wrap around cable labels are produced in die layouts compatible with mainstream cable labeling software templates and ship on cores sized for industrial thermal transfer printers from major brands. Laser sheet versions for desktop printing are also available.
